Alimentazione
Gas
Dimensions WxDxH (mm)
800 x 946 x 900
Min – max temperature (°C)
90 - 190
Number of tanks
2
900
15+15L GAS FRYER
Codice
92FRGMD
92FRGMD-60
TOP with deep-drawn AISI 304 stainless steel tanks with rounded edges for easier cleaning and wide foaming area.
HEATING by burners and stainless steel pipes inside the tanks, with a total power of 20,5kW, adjustable through a SIT 820 valve. Tank temperature adjustable through a working thermostat and an ergonomic control knob.
IGNITION with electronic igniter.
SAFETY guaranteed by flame control via SIT 820 valve, operating thermostat and safety thermostat.
OUTFITTING including filter, basket, tank lid and oil collection tray.
| Gas data | |
|---|---|
| G20 (m³/h) | 2,963 |
| G30 (kg/h) | 2,208 |
| G31 (kg/h) | 2,175 |
| Power (kW) | 28 |
| Specific power (W/L) | 941 |
| Technical data | |
|---|---|
| Dimensions WxDxH (mm) | 800 x 946 x 900 |
| Min – max temperature (°C) | 90 - 190 |
| Number of tanks | 2 |
| Tank dimensions (mm) | 308 x 336 x 275 (x2) |
| Tank capacity (L) | 13,6 / 15 + 13,6 / 15 |
| Control | SIT 820 |
Tank dimensions (mm)
Tank capacity (L)
Control
| Electrical data | |
|---|---|
| Power supply voltage (V) | 220-240V 1N~ |
| Power frequency (Hz) | 50 |
Power supply voltage (V)
Power frequency (Hz)
| Optional | |
|---|---|
| Power supply voltage (V) | 220-240V 1N~ |
| Power frequency (Hz) | 60 |
Accessori
KFR0010
15L FRYER BASKET
KFR0020
1/2 BASKET FOR 15L FRYER
KFR0210
15L BASKET SUPPORT GRID
KFR0040
FRYER LID
KFR0350
OIL COLLECTION TRAY
