17L GAS FRYER
Codice
71FRGMC
71FRGMC-60
TOP with deep-drawn AISI 304 stainless steel tank with rounded edges for easier cleaning and wide foaming area.
HEATING by pair of burners external to the tank with total power of 16kW, adjustable through SIT 820 valve. Internal tank temperature adjustable via working thermostat and ergonomic knob.
IGNITION with electronic igniter.
SAFETY guaranteed by flame control via SIT 820 valve, operating thermostat and safety thermostat.
EQUIPMENT including filter, basket, tank lid and oil collection tray.
| Gas data | |
|---|---|
| G20 (m³/h) | 1,693 |
| G30 (kg/h) | 1,262 |
| G31 (kg/h) | 1,243 |
| Power (kW) | 16 |
| Specific power (W/L) | 941 |
| Technical data | |
|---|---|
| Dimensions WxDxH (mm) | 400 x 746 x 900 |
| Min – max temperature (°C) | 90 - 190 |
| Number of tanks | 1 |
| Tank dimensions WxDxH (mm) | 310 x 344 x 335 |
| Tank capacity (L) | 16 / 18 |
| Control | SIT 820 |
| Electrical data | |
|---|---|
| Power supply voltage (V) | 220-240V 1N~ |
| Power frequency (Hz) | 50 |
| Optional | |
|---|---|
| Power supply voltage (V) | 220-240V 1N~ |
| Power frequency (Hz) | 60 |
